Manufacturer of plastic Lined Piping, Valves & Equipments.
Product Features
- Technically sound designing with time-tested production techniques
- Lining of Pipes & fittings as per ASTM F1545 specifications
- Best quality, certified virgin raw material, purchased only from reputed and approved vendors
- Raw material and component vendors include DuPont® , Dyneon®, Daikin®, Symallit® ,Solvay®, Carbone Lorraine® and other internationally reputed companies.
- Batch no./ serial no. wise component tracking for all items.
- Lining thickness is minimum 3mm for pipes, fittings and valves.
- Special care taken to prevent contamination of lining with thorough cleaning of items to be lined
- PTFE lined Pipes and fittings are provided with adequately higher lining thickness in case of heavy duty and vacuum service.
- Injection / transfer molded fittings and valves are provided with locked lining for safety against vacuum.
- Quality control checks are carried out at all stages of the manufacturing process on all raw materials and components. Material test certificates for major raw-materials provided.
- Routine calibration of measuring and testing instruments.
- lAll finished products are 100% tested
DESIGN SPECIFICATIONS
| REGULAR | ON REQUEST | |
|---|---|---|
| FLANGE DRILLING | ANSI B16.5 150#, DIN PN 10/16 | ANSI 300#, BS TABLE D,E,F |
| PIPES 8 FITTING DESIGN & TESTING | ASTM F1545 | |
| VALVE DESIGN | ASME B16.34 | |
| VALVE TESTING | API 598, EN 12266 Pt 1. |
Product Range & Material Options
| PIPING : REGULAR SIZE RANGE AND LINING OPTIONS | ||
|---|---|---|
| PRODUCT | SIZES | LINING |
| PIPING | 15NB - 400NB | PTFE |
| 15NB - 200NB | PVDF. PP | |
| ELBOWS, REDUCERS, TEES, RED.-FLANGES, BLIND FLANGES, SPACERS, INSTRUMENT TEES. | 15NB - 400NB | PTFE |
| 15NB - 200NB | PFA, FEP, PVDF, PP | |
| STRAINERS, SIGHT GLASS, 'Y '- BRANCH. | 15NB - 150NB | PFA. FEP. PVDF. PP |
| DIP TUBES, SPARGERS. | 15NB - 150NB | PTFE |
| BELLOWS | 25NB - 400NB | PTFE |
Note : Pipes larger than 400NB are made regularly but consideredas columns. Fittings larger than indicated sizes made on request. Linings other than those listed can be provided on request
PIPING : REGULAR SIZE RANGE AND LINING OPTIONS
| PRODUCT | DESIGN | SIZES | BODY LINING | TRIM LINING |
|---|---|---|---|---|
| Ball Valve | 2 pc full port | 15NB 150NB | PFA, FEP, PVDF, PP. | PFA, FEP, PVDF, PP. |
| 2 pc red. port | 25NB-200NB | |||
| Butterfly Valve | Wafer type | Elastomer | PFA, FEP, PVDF, PP | |
| Lug type | ||||
| Diaphragm Valve | Wafer type | PFA, FEP, PVDF, PP. | PTFE + Elastomer | |
| Plug Valve | Reduced port | 15NB-250NB | PFA, FEP, PVDF, PP. | PFA, FEP, PVDF. |
| Ball-check Valve | Solid or lined ball | 15NB-150NB | PTFE, PFA, FEP, PVDF, PP. | PTFE, PFA, FEP. |
| Swing-check Valve | Wafer type | FEP, PVDF, PP. | PFA, FEP, PVDF, PP. |
SHEEL MATERIAL OPTIONS
| PIPE | FLANGES | FITTINGS | VALVES | ||||
|---|---|---|---|---|---|---|---|
| SEAMLESS | FORGED | PLATE | FORGED | CAST | CAST | ||
| REGULAR | CARBON STEEL | ASTM A106 Gr.B | ASTM A105 | ASTM A36/IS2062 | ASTM A234 WPB | ASTM A395 | ASTM A395 |
| ASTM A516 Gr.70 | ASTM A216 WCB | ASTM A216 WCB | |||||
| STAINLESS STEEL | ASTM A312 TP304 | ASTM A182 F304 | ASTM A240 Gr.304 | ASTM A403 WP304 | ASTM A351 Gr. CF8 | ASTM A351 Gr. CF8 | |
| ASTM A312 TP316L | ASTM A182 F316L | ASTM A240 Gr.316L | ASTM A403 WP316L | ||||
| ON REGULAR | STAINLESS STEEL | ASTM A312 TP304L | ASTM A182 F304L | ASTM A240 Gr.304L | ASTM A403 WP304L | ASTM A351 Gr. CF8M | ASTM A351 Gr. CF8M |
| ASTM A312 TP316 | ASTM A182 F316 | ASTM A240 Gr.316 | ASTM A403 WP316 | ||||
| LOW TEMP. CARBON STEEL | ASTM A333 Gr.6 | ASTM A350 LF2 | ASTM A420 Gr.WPL6 | ASTM A352 LCB | ASTM A352 LCB | ||
